Specifications
| Category | Specification / Description |
| Core Processor | Quad-core Arm Cortex-A55 (1.8 GHz) Dual-core Cortex-R8 (800 MHz) Single-core Cortex-M33 (200 MHz) |
| AI Accelerator | DRP-AI3 (8 TOPS dense, 80 TOPS sparse) |
| Video Interfaces (AXON) | • 4 × CSI 4-lane MIPI • 1 × Micro-HDMI |
| Main Interfaces (AXON) | • 2 × USB 3.0 |
| Power | • 2 s–6 s (8 V–27 V) MX3.0 |
| Dimensions & Cooling | • Integrated AI and multi-functional applications • 80 × 50 × 20 mm • No heatsink required |
